Chinese Manufacturer Pragmatic Hot Dipped Galvanized G I Malleable Cast Iron Pipe Fittings tee

Product Categories
Leyon steel Co., Ltd
Contact Now

Chinese Manufacturer Pragmatic Hot Dipped Galvanized G I Malleable Cast Iron Pipe Fittings tee

  • 1
  • 2
  • 3

Brand Name : leyon

Model Number : Malleable Iron Pipe Fitting Tees 90 Degree

Certification : FM/UL

Place of Origin : China

MOQ : 100piece

Price : Negotiable

Payment Terms : Western Union, L/C, T/T, D/P, D/A, MoneyGram

Supply Ability : 10000piece/week

Delivery Time : 25-35days

Packaging Details : 200piece/carton

Material : Iron

Item : 11/4 inch Malleable Iron Pipe Fitting Tees 90 Degree

Specification : Elbow, socket, Tee, Union, Bushing, Plug

Connection : Female forged tee pipe fitting

technology : advanced metallurgical and processing

Treaded : ISO7/1, DIN2999,NPT

Size : 11/4 inch

Dimensions : 8 mm

Contact Now

Look up table of Malleable Iron Pipe Fitting Tees 90 Degree

Material Malleable iron
Standard Thread: ISO 7/1
Dimension ISO 49, DIN 2950,EN10242
Chemical property (C %2.4-2.9), (Si %1.4-1.9), (Mn %0.4-0.65), (P% <0.1), (S% <0.2%)
Physical property Tensile strength>=350Mpa,Elongation>=10% Hardness<=150HB
Testing pressure 2.5Mpa
Working pressure 1.6Mpa
Type Beaded with ribs or banded with ribs
Beaded without ribs or banded without ribs
Round/square
Surface Galvanized/ no galvanized
Color White/black
Model Elbow, Tees, Crosses, Bends, Unions, Bushings, Lateral Braches, Sockets, Nipples, Hexagon/Round, Caps, Plugs, Locknuts, Flanges ,Side Outlet Tees, Side Outlet Elbows and etc
Connection Male, Female
Shape Equal, Reducing
Certificate BSI,ANAB,ISO9001,FM,UL
Application Suitable for pipe connect of steam, air, gas, oil and so on
Buyer’s drawings or designs are available
Package Cartons without pallet
Cartons with pallet
Double woven bags
Or as buyer’s requirements

Delivery details

 According to the quantities and specifications of each order
Normal delivery time is from 30 to 45 days after receiving the deposit

Synoptic table of Malleable Iron Pipe Fitting Tees 90 Degree

Size Inch 1/8 1/4 3/8 1/2 3/4 1 11/4 11/2
mm 6 8 10 15 20 25 32 40
Dim.
(mm)		 A 17.5 20.6 24.1 28.5 33.3 38.1 44.5 49.3
Size Inch 2 21/2 3 4 5 6 8
mm 50 65 80 100 125 150 200
Dim.
(mm)		 A 57.2 68.6 78.2 96.3 114.3 130.3 162

How about the Surface processing for Malleable Iron Pipe Fitting Tees 90 Degree :

  1. Rough casting
  2. Rough shot
  3. Rough casting test
  4. Annealing
  5. Polished
  6. Shaping
  7. Flat
  8. Fine shot
  9. Cooked rough
  10. Pickled
  11. Hot galvanized
  12. Hot galvanized Products

All pipe fittings need packed then placed into the box into the kiln annealing.After annealing , we let dedicated person make destructive testing to mechanical behavior of products , then let someone else make flattening test to products by using hydraulic universal tester , in order to check the toughness of the products , to make sure whether they comply with standard.
